This chip bonder cleaner removes messy and difficult uncured chip bonder with ease
- Ideal for PCB assembly and rework and repair operations
- Dissolves both organic and inorganic deposits including leaded and lead-free solder pastes, light oils, grease, grime, fingerprints
- The chip bonder cleaner also removes some inks and some acrylics
- The bulk (liquid) packaging is perfect for wetting understencil rolls when cleaning solder paste in automatic stencil printers
- Ideal for cleaning misprinted boards
- A unique blend of aliphatic hydrocarbons - safer to use than toluene, acetone and other old-style solvents
- High purity isopropyl alcohol and water mixture
- No residue, no rinsing, 100% VOC so fluid evaporates cleanly
- No rip, no lint, heavy duty fabric wipe – not paper
- 'Slam-Shut” lid minimizes evaporation and keeps the wipes damp
- Economical refills eliminate solid waste and help protect the environment
- There are 100, 8″x 5″ presaturated wipes in each tub
- Completely ozone-safe
- Low GWP
|Part Number||Package||Weight||Size||Technical Data Sheet||Safety Data Sheet|
|EPXW MCC-EPXW||Presaturated Wipe||0.84 kg 1.85 lbs.||20 cm x 12 cm 8 in x 5 in|
|EPXWR MCC-EPXWR||Presaturated Wipe Refill||0.84 kg 1.85 lbs.||20 cm x 12 cm 8 in x 5 in|
|EPXG MCC-EPXG||Minicubitainer||3 kg 6 lbs.||3.8 L 1 Gallon|
|EPXP MCC-EPXP||Cubitainer||14 kg 30 lbs.||19 L 5 Gallons|
|EPXD MCC-EPXD||Drum||178 kg 392 lbs.||208 L 55 Gallons|
|Package||Presaturated Wipe||Presaturated Wipe Refill||Minicubitainer||Cubitainer||Drum|
|Weight||0.84 kg 1.85 lbs.||0.84 kg 1.85 lbs.||3 kg 6 lbs.||14 kg 30 lbs.||178 kg 392 lbs.|
|Size||20 cm x 12 cm 8 in x 5 in||20 cm x 12 cm 8 in x 5 in||3.8 L 1 Gallon||19 L 5 Gallons||208 L 55 Gallons|
|Technical Data Sheet|
|Safety Data Sheet|
|Appearance||Clear, colorless liquid in a white polyester wipe|
|PEL (ppm, 8-hr TWA)||50|
|Boiling Point||248-302°C / 120-150°F|
|Cleaning Strength (Kb)||90|
|Active Ingredients||Aliphatic hydrocarbons|
|Flashpoint||41° C / 106°F|
|Global Warming Rating (100yr)||Zero|
|VOC Organic Content (g/L)||860|
|RoHS & WEEE Compliant|
|Vapor Pressure @ 20ºC||0.62|
